Description
One way and Hybrid are available.
One way: One way ink set (1 type of ink is loaded)
- Versatile use and ink type for direct printing in accordance with material and purpose.
- Four colors for high productivity, six/seven/eight colors* for superior expressiveness.
* Only 8 color ink set is available for reactive dye Rc400/Rc500.
Rich variety of ink types in One way for any printing application
Mimaki offers five ink types -sublimation, dispersant, pigment, reactive, and acid- to meet various application needs.
Application: Apparel, Silk product, Fashion articles, Home fabrics, Car seat, Soft signage etc.
*Click to view larger image.
Print speed (One way ink set)
The Tx300P-1800 MkII optimizes the printing speed and quality to produce the desired print results. For this purpose, it provides a wide range of printing modes, from the draft printing mode (which operates at the maximum speed of 66 m2/h) to high-quality printing mode.
* DD400, TP400, Rc400/500, Ac400 inks cannot print in draft mode.
Hybrid: Hybrid ink set (Two types of inks can be loaded at the same time)
- Able to manage to use two types of ink properly in response to your needs.
- Available to print on both paper and textile with a single printer unit.
- Possible to create printed fabric simply with your existing processing equipment only such as heat press etc.
Service engineers are no longer needed!
You can easily replace platens to suit the media type (textile or paper).
Also high-quality printing can be stably achieved by changing the conveyance route for textile and paper.
Versatile ink combination in Hybrid
Mimaki offers three ink combination to meet various application and media.
Application: Sports apparel, Fashion apparel, Wall paper, Poster, Soft signage etc.
*Click to view larger image.
Print speed (Hybrid ink set)
Ultimate design for usability ensuring high-quality production
New printhead allows printing on various types of textile
While printing on raised fiber surface textiles, a high head gap setting is required to prevent contact between the printhead and the nap. In conventional models, such gap conditions reduce the accuracy of ink droplet placement. However, the new printhead ejects ink droplets at a high speed to maintain the straightness of the droplet direction, and accordingly accurate ink droplet placement is achieved. This enables high-quality printing on napped or thick textiles.
Reliable textile feeding mechanism ensures stable printing
Stable textile feeding and transportation are crucial for direct textile printing. The tension applied to the textile during printing is varied according to changes in the outer diameter of the front and rear rolls. The Tx300P-1800 MKII monitors the applied tension and uniformly applies the optimum tension using the front and rear tension bars. Thus, high-quality printing is achieved during high-speed printing or even when using a large textile roll.
Mimaki’s print technologies for achieving beautiful printing
Mimaki Advanced Pass System 4 (MAPS4) reduces banding
Mimaki’s unique anti-banding technique MAPS4 is an advanced version of MAPS3. To prevent banding, swath boundaries are overprinted, whereas boundaries prone to banding are printed with fewer ink droplets.
Superior inkjet technology
Mimaki’s superior inkjet technology accurately places the ink droplets without losing their perfect circularity. This ensures that texts, lines, and edges are clearly and sharply printed.
Uninterrupted printing solutions
Continuous operation support pack minimizes the downtime
The Nozzle Check Unit (NCU) detects nonfunctioning nozzles and automatically cleans them. If the nozzles fail to operate after cleaning, defective nozzles are replaced by non-defective ones until a technician arrives, and printing is continued. This feature enables uninterrupted print operations and continuous productivity.
Standard features of MBIS3 and UISS deliver continuous printing for a long time.
Large two liter ink packs are installed in MBIS3*1 for long-time continuous printing to reduce operating cost.
As soon as one ink container is empty, UISS*2 automatically provides ink from another container without any interruption to printing.
These systems supply inkcontinuously to ensure unattended continuous printing.
*1 MBIS3: Mimaki Bulk Ink System3
*2 UISS: Uninterrupted Ink Supply System
Software
TxLink4 Lite or RasterLink6Plus is bundled according to user’s request.
Specifications
| Tx300P-1800 MkII | ||
|---|---|---|
| Printhead | On-demand piezo head (4 in-line printheads) | |
| Print resolution | 360 dpi, 540 dpi, 720 dpi, 1,080 dpi, 1,440 dpi | |
| Maximum print width | Textile 1,920 mm (75.6″) / Paper 1,940 mm (76.4″) | |
| Maximum media width | Textile 1,920 mm (75.6″) / 1,950 mm (76.8″) | |
| Ink | Type/Color | Sublimation dye ink (Transfer): Sb411 (Bl, M, Y, K) (*) Sublimation dye ink (Direct): Sb420 (Bl, M, Y, K, Lbl, Lm) Textile pigment ink: TP400 (C, M, Y, K, Bl, R, Lk) Disperse dye ink: DD400 (C, M, Y, K, R, Gray, Violet, Pink) Reactive dye ink: Rc400, Rc500 (C, M, Y, K, Bl, R, Or, Lk) Acid dye ink: Ac400 (C, M, Y, K, Bl, R, Or, Lk) |
| Package size | 2L Ink pack | |
| Media thickness | 1.0 mm or less | |
| Rolled media weight | 40 kg (88 lb) or less / 34 kg (75 lb) or less (when using one-inch holder unit of 1,800mm wide) Please note that the above maximum weight applies on a printed roll including ink weight. |
|
| Media type | Natural fiber (Cotton, Silk, Hemp) Chemical fiber (Polyester, Nylon) *Excluding elastic media Paper |
|
| Certifications | VCCI class A, FCC class A, ETL IEC 60950-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, and EAC |
|
| Interface | USB 2.0 Hi-speed / Ethernet 1000BASE-T | |
| Power supply | Single-phase AC100 – 120V / AC200 – 240V | |
| Power consumption | AC100V: 1.44kW / AC200V: 1.92kW | |
| Operational environment | Temperature: 20 – 30 °C (68 – 86 °F) Humidity: 35 – 65% Rh (Non condensing) |
|
| Dimensions (W × D × H) | 3,200 x 965 x 1,857 mm (126 x 38 x 73 “) | |
| Weight | 260 kg (573.2 lb) | |
* “Sublimation dye ink (transfer)” only when the hybrid ink set is selected
- Some of the samples in this website are artificial renderings.
- Specifications, design and dimensions stated in this website may be subject to change without notice (for technical improvements, etc).
- The corporate names and merchandise names written on this website are the trademark or registered trademark of the respective corporations.
- Inkjet printers print using extremely fine dots, so colors may very slightly vary after replacement of the printing heads. Also note that if using multiple printer units, colors could vary slightly from one unit to other unit due to slight individual differences.
- Depending on image files used for printing, the print quality would be affected when printing in a low-resolution mode with the lowest number of passes.
